Technical data
- Lifting power 100 kg.
- Lifting speed 25 m/min.
- The reel contains max. 100m 4mm-cable wire and a
detachable locking hook.
- The load is prevented from falling by a
self-retaining angular worm gear.
- Driving engine: 2-speed standard drilling machine
1000/2400 r/min. 40/25 Nm.
- Also available a separate electromagnetic brake and a
3m push button remote control.
Equipment
- A cable wire/rope guide pulley to be connected with a
HAKI-connector.
- Rope 10 mm, 12 kN.
- Cable wire reel
|
 |
